Sludge Low Temperature Belt Dryer

1. Strong Desiccation Ability

• It reduces the sludge moisture content by up to 83%to 10%.
• The target moisture content is freely adjusted in the range of 10%-50%.

2. Low Energy Consumption

• Dehumidification energy efficiency ratio (SMER) is as high as 4.2kg H₂O/ kW·h, that is, 4.2kg of water can be removed from sludge per degree of electricity.
• Dehumidification and drying technology is three times more energy-saving than traditional drying technologies.

3. High Safety Performance

• The whole drying process of the system is below 75 degrees. There is no gas overflow during common operation to avoid high temperature and high pressure gas leakage accident.
• During the total drying process, gas oxygen content is lower than 12%, dust concentration lower than 60g/m³ and granular dry mud lower than 40℃ with no explosion risk.

4. Pollution-free

• Low temperature drying inhibits decomposition of odor molecules (H₂S, NH₃, etc.) and eliminates exhaust gas by condensation technology. The enclosed form design prevents odor overflow without complex deodorizing devices.
• Condensed water with low COD can be directly returned to the sewage treatment tank.
• The low temperature sterilization process (pasteurization) continuously 2-3h can effectively eliminate 90% of the bacteria in the sludge.

5. Intelligent Use

• Automatic operation, labor-saving, and remote centralized control.
• Scheduled start and stop, and multi-target selection of moisture content.

6. Wide Application Scope

• Suitable for many kinds of sludge: the sludge with a moisture content of 50%-85% can be fed, and is not easily affected by the physical properties of other sludge.
• Not affected by the external environment and climate, and suitable for domestic and foreign occasions.

7. Modular Design

• The equipment is overall easy to transport and install on site.
• It can be arranged flexibly according to the actual situation of the site.

8. Good Durability

• The whole set of equipment has no wear parts and the transmission parts have high reliability.
• All main components and panels are made of corrosion resistant materials, with an overall service life of up to 15 years.
